Magnetic Crack Detector Portable Yoke Kit

Get a Price/Quote

Magnetic Crack Detector Portable Yoke Kit Specification

Interface Type
Manual / Mechanical

Response Time
Instantaneous

Specimen Size
Flat or round workpieces up to approx. 200mm

Mounting Type
Handheld / Portable

Resolution
0.5 mm (crack width)

Automation Grade
Manual

Equipment Type
Magnetic Crack Detector Portable Yoke

Features
Lightweight, easy to operate, high lifting capacity, rugged design

Temperature
0C to 50C

Frequency
50Hz

Operating Voltage
230V AC

Measuring Range
Crack opening from 0.5 mm onwards

Test Range
Surface & subsurface cracks

Number of Specimens
1 at a time

Power Supply
230V AC, 50Hz

Display Type
No digital display; Visual indication only

Max Height
Yoke opening up to 200 mm

Humidity
80% RH

Accuracy
Detects cracks of 0.5 mm & above

Application
Weld inspection, surface crack detection, non-destructive testing (NDT)

Usage
Magnetic particle inspection (MPI), field and shop use

Capacity
Lifting Power up to 18 kg

Machine Weight
Approx. 3.5 kg

Test Speed
Manual

Test Width
Variable (based on yoke position)

Control Mode
Portable / Handheld

Cord Length
Approx. 2 metres

Protection Class
IP20

Finish
Powder coated

Operating Position
Any orientation

Test Standards
Complies with ASTM E709 & IS: 6410

Field Intensity
AC magnetic field, min. 10,000 A/m at contact points

Visual Indication
Fluorescent / dry magnetic particles (not included)

Safety Feature
Overheating protection

Yoke Type
AC Electromagnetic Yoke

Yoke Material
High-strength alloy steel with insulated handle

Lifting Strength
Min. 18 kg (as per IS: 6410 requirements)

Arm Span
Adjustable, up to 200 mm

Cooling System
Air cooled

Kit Inclusions
Yoke, power cord, test cards, carrying case, operation manual

About Magnetic Crack Detector Portable Yoke Kit

Experience unrivaled accuracy with the top-rated Magnetic Crack Detector Portable Yoke Kit-your gilt-edged solution for weld inspection and non-destructive testing. Expertly crafted with a high-strength, insulated alloy steel yoke, this virtuoso device offers dependable lifting power of up to 18 kg and an adjustable arm span of 200 mm. Affordable yet high-performing, it meets rigorous ASTM E709 & IS: 6410 standards, providing access to reliable MPI testing on both flat and round workpieces. Lightweight, portable, and equipped with essential accessories, it ensures effortless operation and superior defect detection every time.

Versatile Applications and Features of the Magnetic Crack Detector Portable Yoke Kit

Designed for weld inspection and surface crack detection, this portable yoke kit excels in both field and shop environments. Its rugged construction supports application on flat or round pieces up to 200 mm, using dry or fluorescent magnetic particles. Lightweight and easy to operate, its high-strength build, adjustable arm span, and advanced overheating protection deliver safety and efficiency-making it indispensable for non-destructive testing across multiple industries.

Payment Terms, Domestic Market Focus, and Certifications

The Magnetic Crack Detector Portable Yoke Kit is available at an attractive rate for swift sale, with expedited arrival across India's main domestic markets. Manufactured to meet stringent ASTM E709 and IS: 6410 certifications, it guarantees unrivaled quality. Flexible payment terms are offered to suit diverse procurement needs, ensuring that customers have easy access to this top-tier inspection equipment backed by recognized industry standards.

FAQ's of Magnetic Crack Detector Portable Yoke Kit:

Q: How does the Magnetic Crack Detector Portable Yoke Kit detect cracks?

A: This kit uses an AC electromagnetic yoke to generate a strong magnetic field, enabling detection of surface and subsurface cracks by applying dry or fluorescent magnetic particles, with visual indications of defects as small as 0.5 mm.

Q: What are the primary uses of the Magnetic Crack Detector Portable Yoke Kit?

A: It is primarily used for weld inspection, surface and near-surface crack detection, and general non-destructive testing (NDT) on both flat and round workpieces.

Q: Is the Magnetic Crack Detector suitable for field as well as shop use?

A: Yes, its compact, lightweight, and portable design makes it ideal for both on-site and stationary shop applications, ensuring flexibility in usage.

Q: When should I use dry versus fluorescent magnetic particles?

A: Dry magnetic particles are suitable for field use and quick inspections, while fluorescent particles are preferred in controlled environments for enhanced visibility under UV light during detailed inspections.

Q: What is the process for operating the Magnetic Crack Detector Portable Yoke Kit?

A: Simply position the yoke on the test specimen, connect to power, and apply magnetic particles. Observe the formation of indications visually to identify and assess any cracks present.

Q: Where can I purchase the Magnetic Crack Detector Portable Yoke Kit?

A: You can access this product through trusted suppliers, exporters, manufacturers, and service providers across India, many of whom offer swift delivery to main domestic markets.
